Quectel EC200T Series User Manual

LTE Standard Module Series
EC200T Series Hardware Design
EC200T_Series_Hardware_Design 80 / 90
WCDMA B1/B5/B8 24 dBm +1/-3 dB < -49 dBm
LTE-FDD B1/B3/B5/B8 23 dBm ±2 dB < -39 dBm
LTE-TDD B34/B38/B39/B40/B41 23 dBm ±2 dB < -39 dBm
Table 38: EC200T-EU RF Output Power
Frequency Max. Min.
EGSM900 33 dBm ±2 dB 5 dBm ±5 dB
DCS1800 30 dBm ±2 dB 0 dBm ±5 dB
EGSM900 (8-PSK) 27 dBm ±3 dB 5 dBm ±5 dB
DCS1800 (8-PSK) 26 dBm ±3 dB 0 dBm ±5 dB
WCDMA B1/B8 24 dBm +1/-3 dB < -49 dBm
LTE-FDD B1/B3/B7/B8/B20/B28 23 dBm ±2 dB < -39 dBm
LTE-TDD B38/B40/B41 23 dBm ±2 dB < -39 dBm
Table 39: EC200T-AU* RF Output Power
Frequency Max. Min.
EGSM900 33 dBm ±2 dB 5 dBm ±5 dB
GSM850 33 dBm ±2 dB 5 dBm ±5 dB
DCS1800 30 dBm ±2 dB 0 dBm ±5 dB
PCS1900 30 dBm ±2 dB 0 dBm ±5 dB
EGSM900 (8-PSK) 27 dBm ±3 dB 5 dBm ±5 dB
EGSM850 (8-PSK) 27 dBm ±3 dB 5 dBm ±5 dB
DCS1800 (8-PSK) 26 dBm ±3 dB 0 dBm ±5 dB
PCS1900 (8-PSK) 26 dBm ±3 dB 0 dBm ±5 dB
WCDMA B1/B2/B4/B5/B8 24 dBm +1/-3 dB < -49 dBm
