LTE-TDD B39 (10 MHz) -97 dBm -97.5 dBm -100 dBm -96.3 dBm
LTE-TDD B40 (10 MHz) -97 dBm -97 dBm -100 dBm -96.3 dBm
LTE-TDD B41 (10 MHz) -96 dBm -97 dBm -99 dBm -94.3 dBm
Table 41: EC200T-EU Conducted RF Receiving Sensitivity
Frequency
Receiving Sensitivity (Typ.)
3GPP (SIMO)
Primary Diversity SIMO
EGSM900 TBD NA NA -102 dBm
DCS1800 TBD NA NA -102 dBm
WCDMA B1 TBD NA NA -106.7 dBm
WCDMA B8 TBD NA NA -103.7 dBm
LTE-FDD B1 (10 MHz) TBD TBD TBD -96.3 dBm
LTE-FDD B3 (10 MHz) TBD TBD TBD -93.3 dBm
LTE-FDD B7 (10 MHz) TBD TBD TBD -94.3 dBm
LTE-FDD B8 (10 MHz) TBD TBD TBD -93.3 dBm
LTE-TDD B20 (10 MHz) TBD TBD TBD -93.3 dBm
LTE-TDD B28 (10 MHz) TBD TBD TBD -94.8 dBm
LTE-TDD B38 (10 MHz) TBD TBD TBD -96.3 dBm
LTE-TDD B40 (10 MHz) TBD TBD TBD -96.3 dBm
LTE-TDD B41 (10 MHz) TBD TBD TBD -94.3 dBm
Table 42: EC200T-AU
* Conducted RF Receiving Sensitivity
Frequency
Receiving Sensitivity (Typ.)
3GPP (SIMO)
Primary Diversity SIMO
GSM850 TBD NA NA -102 dBm
EGSM900 TBD NA NA -102 dBm
