LTE Standard Module Series
EC21_Series_Hardware_Design
23
/ 118
2.3. Functional Diagram
The following figure shows a block diagram of EC21 series and illustrates the major functional parts.
Power management
Baseband
DDR+NAND flash
Radio frequency
Peripheral interfaces
Figure 1: Functional Diagram
Firmware Upgrade USB 2.0 interface or DFOTA
RoHS All hardware components are fully compliant with EU RoHS directive
