Table 30: Conducted RF Receiving Sensitivity of EC25-AFX Mini PCIe
Table 31: Conducted RF Receiving Sensitivity of EC25-EU Mini PCIe
LTE-FDD B5 (10MHz)
-98.0dBm
-98.5dBm
-100.5dBm
-94.3dBm
LTE-FDD B12 (10MHz)
-99.0dBm
-99.5dBm
-100.5dBm
-93.3dBm
LTE-FDD B13 (10MHz)
-98.5dBm
-99.5dBm
-100.7dBm
-93.3dBm
LTE-FDD B14 (10MHz)
-99.4dBm
-99.5dBm
-100.9dBm
-93.3dBm
LTE-FDD B66 (10MHz)
-97.5dBm
-98.5dBm
-99.6dBm
-95.8dBm
LTE-FDD B71 (10MHz)
-98.6dBm
-99.5dBm
-100dBm
-93.5dBm
Frequency Bands
Primary
Diversity
SIMO
1)
3GPP (SIMO)
WCDMA B2
-109.6dBm
-110dBm
-110.4dBm
-104.7dBm
WCDMA B4
-109.6dBm
-110dBm
-110.6dBm
-106.7dBm
WCDMA B5
-110.5dBm
-110dBm
-110.7dBm
-104.7dBm
LTE-FDD B2 (10MHz)
-98.0dBm
-98.5dBm
-100.5dBm
-94.3dBm
LTE-FDD B4 (10MHz)
-97.6dBm
-98.2dBm
-99.5dBm
-93.3dBm
LTE-FDD B5 (10MHz)
-98.0dBm
-98.5dBm
-100.5dBm
-94.3dBm
LTE-FDD B12 (10MHz)
-99.0dBm
-99.5dBm
-100.5dBm
-93.3dBm
LTE-FDD B13 (10MHz)
-98.5dBm
-99.7dBm
-100.8dBm
-93.3dBm
LTE-FDD B14 (10MHz)
-99.4dBm
-99.5dBm
-100.9dBm
-93.3dBm
LTE-FDD B66 (10MHz)
-97.5dBm
-98.5dBm
-99.6dBm
-95.8dBm
LTE-FDD B71 (10MHz)
-98.8dBm
-99.7dBm
-100.5dBm
-93.5dBm
Frequency Bands
Primary
Diversity
SIMO
1)
3GPP (SIMO)
EGSM900
-108dBm
/
/
-102.0dBm
DCS1800
-108.6dBm
/
/
-102.0dbm
