Table 32: Conducted RF Receiving Sensitivity of EC25-EC Mini PCIe
WCDMA B1
-110dBm
-109dBm
/
-106.7dBm
WCDMA B8
-110dBm
-111dBm
/
-103.7dBm
LTE-FDD B1 (10MHz)
-98.2dBm
-99.0dBm
-101.2dBm
-96.3dBm
LTE-FDD B3 (10MHz)
-97.7dBm
-99.8dBm
-101.0dBm
-93.3dBm
LTE-FDD B7 (10MHz)
-96.7dBm
-98.5dBm
-100.2dBm
-94.3dBm
LTE-FDD B8 (10MHz)
-98.2dBm
-100.4dBm
-101.7 dBm
-93.3dBm
LTE-FDD B20 (10MHz)
-98.2dBm
-100.8dBm
-101.7dBm
-93.3dBm
LTE-FDD B28 (10MHz)
-98.2dBm
-100.5dBm
-101.7dBm
-94.8dBm
LTE-TDD B38 (10MHz)
-95dBm
-97.0dBm
-99.7dBm
-96.3dBm
LTE-TDD B40 (10MHz)
-95.9dBm
-98.0dBm
-100.2dBm
-96.3dBm
LTE-TDD B41 (10MHz)
-94.8dBm
-97.0dBm
-99.7dBm
-94.3dBm
Frequency Bands
Primary
Diversity
SIMO
1)
3GPP (SIMO)
EGSM900
-108.8dBm
/
/
-102.0dBm
DCS1800
-109.0dBm
/
/
-102.0dbm
WCDMA B1
-110.5dBm
/
/
-106.7dBm
WCDMA B8
-110.5dBm
/
/
-103.7dBm
LTE-FDD B1 (10MHz)
-98.0dBm
-98.0dBm
-101.0dBm
-96.3dBm
LTE-FDD B3 (10MHz)
-96.5dBm
-98.5dBm
-100.0dBm
-93.3dBm
LTE-FDD B7 (10MHz)
-97.0dBm
-95.5dBm
-99.5dBm
-94.3dBm
LTE-FDD B8 (10MHz)
-97.0dBm
-97.0dBm
-101.0dBm
-93.3dBm
LTE-FDD B20 (10MHz)
-97.5dBm
-99.0dBm
-101.0dBm
-93.3dBm
LTE-FDD B28 (10MHz)
-98.6dBm
-98.7dBm
-101.5dBm
-94.8dBm
