Quectel EC25 Mini PCIe - Page 58

LTE Standard Module Series
EC25 Mini PCIe Hardware Design
EC25_Mini_PCIe_Hardware_Design 57 / 79
LTE-FDD PF=128 (USB disconnected)
4.4
mA
LTE-TDD PF=64 (USB disconnected)
5.1
mA
LTE-TDD PF=128 (USB disconnected)
4.4
mA
Idle state
WCDMA PF=64 (USB disconnected)
31.5
mA
WCDMA PF=64 (USB connected)
43.5
mA
LTE-FDD PF=64 (USB disconnected)
32.3
mA
LTE-FDD PF=64 (USB connected)
45.4
mA
LTE-TDD PF=64 (USB disconnected)
32.3
mA
LTE-TDD PF=64 (USB connected)
43.3
mA
WCDMA data
transfer
(GNSS OFF)
WCDMA B1 HSDPA @22.55dBm
829.0
mA
WCDMA B1 HSUPA @22.25dBm
848.2
mA
WCDMA B6 HSDPA @22.79dBm
649.2
mA
WCDMA B6 HSUPA @22.59dBm
661.4
mA
WCDMA B8 HSDPA @22.71dBm
691.0
mA
WCDMA B8 HSUPA @22.63dBm
700.0
mA
WCDMA B19 HSDPA @22.77dBm
644.2
mA
WCDMA B19 HSUPA @22.53dBm
657.6
mA
LTE data
transfer
(GNSS OFF)
LTE-FDD B1 @23.15dBm
1045.0
mA
LTE-FDD B3 @23.29dBm
1070.0
mA
LTE-FDD B8 @23.29dBm
867.3
mA
LTE-FDD B18 @23.82dBm
947.7
mA
LTE-FDD B19 @23.78dBm
955.1
mA
LTE-FDD B26 @23.22dBm
924.9
mA
LTE-TDD B41 @22.95dBm
609.6
mA
WCDMA
WCDMA B1 @23.39dBm
969.6
mA
