LTE Standard Module Series
EC25 Mini PCIe Hardware Design
EC25_Mini_PCIe_Hardware_Design 58 / 79
Table 40: Current Consumption of EC25-E Mini PCIe
voice call
WCDMA B6 @23.36dBm
692.3
mA
WCDMA B8 @23.54dBm
763.9
mA
WCDMA B19 @23.29dBm
682.1
mA
Parameter
Description
Conditions
Typ.
Unit
I
VBAT
Sleep state
AT+CFUN=0 (USB disconnected)
3.9
mA
GSM DRX=2 (USB disconnected)
5.1
mA
GSM DRX=9 (USB disconnected)
4.3
mA
WCDMA PF=64 (USB disconnected)
5.5
mA
WCDMA PF=128 (USB disconnected)
4.8
mA
LTE-FDD PF=64 (USB disconnected)
5.8
mA
LTE-FDD PF=128 (USB disconnected)
5.0
mA
LTE-TDD PF=64 (USB disconnected)
5.8
mA
LTE-TDD PF=128 (USB disconnected)
4.9
mA
Idle state
GSM DRX=5 (USB disconnected)
30.0
mA
GSM DRX=5 (USB connected)
43.0
mA
WCDMA PF=64 (USB disconnected)
31.0
mA
WCDMA PF=64 (USB connected)
45.0
mA
LTE-FDD PF=64 (USB disconnected)
31.0
mA
LTE-FDD PF=64 (USB connected)
44.0
mA
LTE-TDD PF=64 (USB disconnected)
32.0
mA
LTE-TDD PF=64 (USB connected)
44.0
mA
GPRS data
transfer
(GNSS OFF)
EGSM900 4DL/1UL @33.08dBm
372.0
mA
EGSM900 3DL/2UL @31.03dBm
626.0
mA
