Quectel EC25 Mini PCIe - Page 60

LTE Standard Module Series
EC25 Mini PCIe Hardware Design
EC25_Mini_PCIe_Hardware_Design 59 / 79
EGSM900 2DL/3UL @29.86dBm
706.0
mA
EGSM900 1DL/4UL @29.44dBm
767.0
mA
DCS1800 4DL/1UL @30.39dBm
262.0
mA
DCS1800 3DL/2UL @30.19dBm
417.0
mA
DCS1800 2DL/3UL @30.02dBm
564.0
mA
DCS1800 1DL/4UL @29.86dBm
709.0
mA
EDGE data
transfer
(GNSS OFF)
EGSM900 4DL/1UL @27.59dBm
233.0
mA
EGSM900 3DL/2UL @27.45dBm
370.0
mA
EGSM900 2DL/3UL @27.31dBm
500.0
mA
EGSM900 1DL/4UL @27.14dBm
623.0
mA
DCS1800 4DL/1UL @26.24dBm
224.0
mA
DCS1800 3DL/2UL @26.13dBm
334.0
mA
DCS1800 2DL/3UL @25.97dBm
440.0
mA
DCS1800 1DL/4UL @25.82dBm
553.0
mA
WCDMA data
transfer
(GNSS OFF)
WCDMA B1 HSDPA @22.49dBm
798.0
mA
WCDMA B1 HSUPA @21.87dBm
788.0
mA
WCDMA B5 HSDPA @22.66dBm
781.0
mA
WCDMA B5 HSUPA @21.99dBm
770.0
mA
WCDMA B8 HSDPA @22.23dBm
655.0
mA
WCDMA B8 HSUPA @21.68dBm
659.0
mA
LTE data
transfer
(GNSS OFF)
LTE-FDD B1 @23.12dBm
940.0
mA
LTE-FDD B3 @22.75dBm
989.0
mA
LTE-FDD B5 @22.92dBm
962.0
mA
LTE-FDD B7 @23.42dBm
1188.0
mA
LTE-FDD B8 @22.97dBm
911.0
mA
