LTE Standard Module Series
EC25 Mini PCIe Hardware Design
EC25_Mini_PCIe_Hardware_Design 60 / 79
Table 41: Current Consumption of EC25-V Mini PCIe
Table 42: Current Consumption of EC25-AF Mini PCIe
LTE-FDD B20 @22.51dBm
946.0
mA
LTE-TDD B38 @22.58dBm
686.0
mA
LTE-TDD B40 @22.31dBm
576.0
mA
LTE-TDD B41 @22.03dBm
611.0
mA
GSM
voice call
EGSM900 PCL=5 @33.31dBm
367.0
mA
DCS1800 PCL=0 @29.48dBm
248.0
mA
WCDMA voice
call
WCDMA B1 @23.18dBm
868.0
mA
WCDMA B5 @22.62dBm
808.0
mA
WCDMA B8 @23.02dBm
728.0
mA
Parameter
Description
Conditions
Typ.
Unit
I
VBAT
Sleep state
AT+CFUN=0 (USB disconnected)
3.4
mA
LTE-FDD PF=64 (USB disconnected)
4.8
mA
LTE-FDD PF=128 (USB disconnected)
4.3
mA
Idle state
LTE-FDD PF=64 (USB disconnected)
30.0
mA
LTE-FDD PF=64 (USB connected)
42.0
mA
LTE data
transfer
(GNSS OFF)
LTE-FDD B4 @23.3dBm
873.0
mA
LTE-FDD B13 @22.13dBm
638.0
mA
Parameter
Description
Conditions
Typ.
Unit
I
VBAT
Sleep state
AT+CFUN=0 (USB disconnected)
2.2
mA
WCDMA PF=64 (USB disconnected)
3.1
mA
WCDMA PF=128 (USB disconnected)
2.8
mA
