EGSM900 2DL/3UL @29.90dBm
631.4
mA
EGSM900 1DL/4UL @28.70dBm
725.3
mA
DCS1800 4DL/1UL @30.02dBm
221.8
mA
DCS1800 3DL/2UL @29.12dBm
319.6
mA
DCS1800 2DL/3UL @26.98dBm
384.8
mA
DCS1800 1DL/4UL @25.80dBm
468.3
mA
PCS1900 4DL/1UL @30.22dBm
243.2
mA
PCS1900 3DL/2UL @28.93dBm
336.9
mA
PCS1900 2DL/3UL @27.00dBm
398.3
mA
PCS1900 1DL/4UL @25.86dBm
478.0
mA
EDGE data
transfer
(GNSS OFF)
GSM850 4DL/1UL @27.45dBm
253.6
mA
GSM850 3DL/2UL @26.29dBm
389.8
mA
GSM850 2DL/3UL @23.96dBm
515.4
mA
GSM850 1DL/4UL @22.72dBm
647.6
mA
EGSM900 4DL/1UL @27.63dBm
257.2
mA
EGSM900 3DL/2UL @26.45dBm
399.1
mA
EGSM900 2DL/3UL @24.27dBm
515.3
mA
EGSM900 1DL/4UL @22.99dBm
642.0
mA
DCS1800 4DL/1UL @26.55dBm
196.7
mA
DCS1800 3DL/2UL @25.90dBm
304.4
mA
DCS1800 2DL/3UL @23.91dBm
408.8
mA
DCS1800 1DL/4UL @22.61dBm
524.3
mA
PCS1900 4DL/1UL @26.67dBm
194.7
mA
PCS1900 3DL/2UL @25.88dBm
299.1
mA
PCS1900 2DL/3UL @23.85dBm
399.7
mA
