PCS1900 1DL/4UL @22.73dBm
510.1
mA
WCDMA data
transfer
(GNSS OFF)
WCDMA B1 HSDPA @21.54dBm
679.4
mA
WCDMA B1 HSUPA @21.82dBm
721.1
mA
WCDMA B2 HSDPA @22.10dBm
723.0
mA
WCDMA B2 HSUPA @21.84dBm
708.6
mA
WCDMA B5 HSDPA @23.27dBm
672.6
mA
WCDMA B5 HSUPA @22.93dBm
672.0
mA
WCDMA B8 HSDPA @21.70dBm
667.9
mA
WCDMA B8 HSUPA @21.12dBm
674.5
mA
LTE data
transfer
(GNSS OFF)
LTE-FDD B1 @23.50dBm
963.9
mA
LTE-FDD B2 @22.95dBm
941.7
mA
LTE-FDD B3 @23.27dBm
856.4
mA
LTE-FDD B4 @23.28dBm
817.1
mA
LTE-FDD B5 @23.09dBm
724.5
mA
LTE-FDD B7 @23.09dBm
945.2
mA
LTE-FDD B8 @23.64dBm
888.3
mA
LTE-FDD B28 @22.79dBm
964.5
mA
LTE-TDD B40 @23.70dBm
428.9
mA
GSM
voice call
GSM850 PCL5 @32.75dBm
346.9
mA
EGSM900 PCL5 @33.53dBm
385.3
mA
DCS1800 PCL0 @30.03dBm
210.2
mA
PCS1900 PCL0 @29.94dBm
219.6
mA
WCDMA
voice call
WCDMA B1 @23.75dBm
785.1
mA
WCDMA B2 @23.07dBm
804.5
mA
WCDMA B5 @23.31dBm
701.8
mA
