Quectel FC80A User Manual

Wi-Fi&Bluetooth Module Series
FC80A_Hardware_Design 28 / 43
Table 23: Power consumption in ANT_WIFI1 (SISO Mode, Unit: mA)
Description
Conditions
VBAT (3.3 V)
VDDIO (1.8 V)
TX (5 GHz) 54 Mbps
291
0.40
802.11ac
TX (5 GHz) VHT20 MCS0
388
0.44
TX (5 GHz) VHT20 MCS8
361
0.41
TX (5 GHz) VHT40 MCS0
380
0.45
TX (5 GHz) VHT40 MCS9
287
0.44
TX (5 GHz) VHT80 MCS0
579
0.71
TX (5 GHz) VHT80 MCS9
374
0.58
Description
Conditions
VBAT (3.3 V)
VDDIO (1.8 V)
802.11b
TX (2.4 GHz) 1 Mbps
513
0.88
TX (2.4 GHz) 11 Mbps
482
0.88
802.11g
TX (2.4 GHz) 6 Mbps
473
0.89
TX (2.4 GHz) 54 Mbps
310
0.90
802.11n
TX (2.4 GHz) HT20 MCS0
438
0.88
TX (2.4 GHz) HT20 MCS7
292
0.88
TX (5 GHz) HT20 MCS0
383
0.44
TX (5 GHz) HT20 MCS7
294
0.41
TX (5 GHz) HT40 MCS0
396
0.46
TX (5 GHz) HT40 MCS7
294
0.44
802.11a
TX (5 GHz) 6 Mbps
383
0.43
TX (5 GHz) 54 Mbps
298
0.41
802.11ac
TX (5 GHz) VHT20 MCS0
382
0.43
TX (5 GHz) VHT20 MCS8
362
0.41
