Quectel FC80A - Conducted RF Receiving Sensitivity

Wi-Fi&Bluetooth Module Series
FC80A_Hardware_Design 31 / 43
4.5.2. Conducted RF Receiving Sensitivity
Table 27: Conducted RF Receiving Sensitivity at 2.4 GHz
Table 28: Conducted RF Receiving Sensitivity at 5 GHz
Description
Receiving Sensitivity (Typ.)
Unit
802.11b @ 1 Mbps
-98
dBm
802.11b @ 11 Mbps
-90
dBm
802.11g @ 6 Mbps
-94
dBm
802.11g @ 54 Mbps
-77
dBm
802.11n, HT20 @ MCS0
-93
dBm
802.11n, HT20 @ MCS7
-76
dBm
Description
Receiving Sensitivity (Typ.)
Unit
802.11a @ 6 Mbps
-92
dBm
802.11a @ 54 Mbps
-76
dBm
802.11n, HT20 @ MCS0
-92
dBm
802.11n, HT20 @ MCS7
-74
dBm
802.11n, HT40 @ MCS0
-90
dBm
802.11n, HT40 @ MCS7
-71
dBm
802.11ac, VHT20 @ MCS0
-92
dBm
802.11ac, VHT20 @ MCS8
-69
dBm
802.11ac, VHT40 @ MCS0
-90
dBm
802.11ac, VHT40 @ MCS9
-65
dBm
802.11ac, VHT80 @ MCS0
-87
dBm
802.11ac, VHT80 @ MCS9
-62
dBm
