GNSS Module Series
LC86L EVB User Guide
LC86L_EVB_User_Guide 19 /22
Figure 13: PowerGPS main interface (connected)
5.1.1. PowerGPS interface description
On the PowerGPS interface, GNSS information such as CNR message, time, position, speed and
precision can be viewed. Explanations are listed in the table below.
Table 6: Explanations of PowerGPS Interface
⚫ SV with PRN 65. If the position of SV is near to the centre of
the Sky View, the elevation angle of SV is close to 90°.
⚫ Blue means this satellite is being tracked.
To Next Page
