GNSS Module Series

LC86L EVB User Guide

LC86L_EVB_User_Guide 8 /22

Table 1: Interfaces of LC86L EVB

SN.

Designator

Description

A

Y404

LC86L module

B

J403

Antenna connector

C

S101

Power switch

D

J103

Micro-USB connector

E

S302

Force_on button

F

J301

Reset button

G

U201

USB and SD switch

H

D303,D304,D305,D306,D307

Indication LEDs

I

S401

Boot button
