M10 EVB User Guide
M10_EVB_User_Guide Confidential / Released 12 / 31
3 Interface Application
3.1. Power Interface
Figure 4: Power interface
Table 1: Pin Description
Pin
Signal
I/O
Description
1
Adapter input
I
5V/2A DC source input
2
GND
