Quectel M10

GSM /GPRS Module
M10 EVB User Guide
M10_EVB_User_Guide Confidential / Released 30 / 31
Table 15: Pin Definition of the 60-pin DIP Connector
PIN NO.
PIN NAME
I/O
PIN NO.
PIN NAME
I/O
1
VBAT
I
2
GND
3
VBAT
I
4
GND
5
VBAT
I
6
GND
7
VBAT
I
8
GND
9
VBAT
I
10
GND
11
VCHG
I
12
ADC0
I
13
ADC1
I
14
VRTC
I/O
15
VDD_EXT
O
16
NETLIGHT
O
17
PWRKEY
I
18
KBR0
O
19
STATUS
O
20
KBR1
O
21
GPIO0
I/O
22
KBR2
O
23
BUZZER
Reserved
24
TXD3
O
25
SIM_VDD
O
26
RXD3
I
27
SIM_RST
O
28
KBC0
I
29
SIM_DATA
I/O
30
KBC1
I
31
SIM_CLK
O
32
KBC2
I
33
SIM_PRESENCE
I
34
LIGHT_MOS
O
35
GPIO1_KBC5
I/O
36
EMERG_OFF
I
37
DCD
O
38
SD_CMD
O
39
DTR
I
40
SD_CLK
O
41
RXD
I
42
SD_DATA
I/O
43
TXD
O
44
DISP_A0
Reserved
45
RTS
I
46
DISP_RST
Reserved
47
CTS
O
48
DBG_RXD
I
49
RI
O
50
DBG_TXD
O
51
AGND
52
AGND
53
SPK1P
O
54
MIC1P
I
55
SPK1N
O
56
MIC1N
I
57
SPK2P
O
58
MIC2P
I
59
AGND
60
MIC2N
I
