Operating status LED
Figure 11: Operating st
atus indication LED
Table 9: Operating status indication L
ED
Part
Name
I/O
Description
L1
5V O
N/OFF indicator
O
On: VBA
T ON
Off: VBA
T OFF
L2 GSM_NET
status
indicator
O
Blinking dif
ferently
to indicate
various GSM networ
k status
M20_EVB_UGD_V1.01
-
1
7
-
Quectel
17
19
