32 – 02|2016 – Subject to change. Sportrex2 – Q6000A
Appendix
Technical data
External dimensions
Length (without buggy wheel) 98 cm
Length (with buggy wheel) 116 cm
Length (with tow bar) 144 cm
Width (external width from wheel to wheel) 85 cm
Height (from ground to cabin roof) 90 cm
Height of push handle (lowest / highest set dimension) 74 cm / 107 cm
Pack size of the collapsed cabin (L x W x H) 113 cm x 72 cm x 30 cm
Internal dimensions
Seat width (max. width at shoulder height, across both sides) 64 cm
Seat height (max. height between seat and cabin roof) 74 cm
Legroom (max. length between backrest and foot rest) 57 cm
Storage space behind the backrest (L x W x H)
33 cm x 58 cm x 28 cm (approx. 55 l)
Weights
Cabin (incl. push handle) 10.9 kg
1 x 20" wheel / 1x buggy wheel / 1 x tow bar 1.3 kg / 1.5 kg /0.8 kg
Permitted total weight 60 kg
Max. load (Trailer or Buggy & Walker mode) 44 kg
Wheels
Wheel
Type 20" spoked wheel, push-in axle
Tyres 20 x 2.0 (54-406)
Hose size 20", 20 – 50 mm wide
Valve type Car valve (Schrader)
Recommended / maximum air pressure 1.7 – 2.4 bar / 2.7 bar
Buggy wheel
Type 8.5" air wheel
Valve type Car valve (Schrader)
Maximum air pressure 2 bar
Ambient conditions
Storage location dry, ventilated, no direct sunlight
Temperature range for storage -23 °C – 65 °C
