Quest DEH 3000R Installation, Operation and Maintenance Instructions
4
www.QuestProtect.com
sales@questprotect.com
2.2 Remote Sensor Install Instructions
This section is applicable only to customers who have purchased a remote
sensor package. The standard DEH 3000 controller does not offer remote
functionality.
2.3 Remote Sensor Usage
IMPORTANT!
•Theuseofspraypaintonthesensorhousingmaydamagethesensorandisnotcoveredbytheproduct
warranty.
Theremotesensingoptionisusedwhenaninstallationrequiresmountingthehumidityandtemperaturesensor
outoftheconditionedspaceorwhenitisdesiredtospecicallymonitorandcontroltheconditionsataparticular
locationinalargerconditionedspace.
Boththeneedforandlocationoftheremotesensorshouldbedeterminedbyaheating/coolingprofessional.
2.4 Remote Sensor Wiring Instructions
1.Routingsignalwires:
Youwillberequiredtosupplyandroute24gauge,4conductorsolidwire(2-linetelephonewire)betweenthe
DEH3000Rcontrollerandtheremotesensorlocation.•Donotrunwireslongerthan100ft.
•Theuseof24gaugewireisoptimal.Thinnergaugewiremaylimitsensordistance.Thickergaugeswillnotwork
withspliceconnectorsprovided.
•Avoidroutingparalleltohighvoltagewiring.
•Maintainadistanceof2ft.ormorefromhighvoltagelines.
2.Sensorconnection:
Thesensorcanbemountedtoawallorceilingsurface.Idealsensorlocationis5ft.abovetheoor.Wires
shouldexitthrougha½”diameterholeinthemountingsurfaceatthemountinglocation.Usetheprovidedsplice
