Quick CHC 1202 M - Page 3

CHC1202M IT GB - REV005B
3
Pag. 32 CHARACTERISTICS AND INSTALLATION
Pag. 33 INSTALLATION - Installing the laps sensor
Pag. 34 INSTALLATION - Installing the magnet - Installing the sensor
Pag. 35 INSTALLATION - Installing the chain counter
Pag. 36 INSTALLATION - Panel-mounting - Installing the chain counter behind the panel
Pag. 37 INSTALLATION - Electric connections
Pag. 38 INSTALLATION - Installing the terminals
Pag. 39 INSTALLATION - Chain counter calibration
Pag. 40 CHAIN COUNTER OPERATION - Main window
Pag. 41 CHAIN COUNTER OPERATION - Windlass electric drive
Pag. 42 CHAIN COUNTER OPERATION - Monitoring
Pag. 43 SETTING THE CHAIN COUNTER - The structure of the menus
Pag. 44 SETTING THE CHAIN COUNTER - Settings menu - Counter reset / Functions
Pag. 46 SETTING THE CHAIN COUNTER - Settings menu - Personal set
Pag. 48 SETTING THE CHAIN COUNTER - Settings menu - Date and time
Pag. 49 SETTING THE CHAIN COUNTER - Settings menu - Language / Calibration / Set measure
Pag. 50 SETTING THE CHAIN COUNTER - Settings menu - Calibration / Gypsy lap
Pag. 51 SETTING THE CHAIN COUNTER - Settings menu - Auto free fall
Pag. 52 SETTING THE CHAIN COUNTER - Settings menu - Automatic calibration
Pag. 53 SETTING THE CHAIN COUNTER - Settings menu - Utility
Pag. 55 SETTING THE CHAIN COUNTER - Settings menu - CAN configuration
Pag. 56 SYSTEM ERRORS AND FAULTS
Pag. 59 MAINTENANCE - TECHNICAL DATA
