SETTING THE CHAIN COUNTER
Use keys
p
and
q
(UP and DOWN) to select the data items within the menu and to
change the parameters.
The data item that has been currently selected appears in REVERSE.
Use key
=
(SELECT) to confirm the option or the parameter selected.
The following data items are provided on the settings menu, with the MASTER chain
counter present on the network:
SETTING THE CHAIN COUNTER
The chain counter has a several functions that can be personalized to satisfy user's
requirements. To go to the setting menu, press and release key
=
(SELECT) for
more than 3 seconds.
As soon as the key is released a window similar to the one shown below is
displayed:
SETTINGS
COUNTER RESET
FUNCTIONS
PERSONAL
SET
LANGUAGE
CALIBRATION
AUTO CALIBRATE
THE STRUCTURE
OF THE MENUS:
COUNTER RESET
FUNCTIONS
PERSONAL SET
LANGUAGE
CALIBRATION
AUTO CALIBRATE
UTILITY
CAN CONFIG
EXIT
UP ALARM
AUTO DOWN
CONTRAST
LIGHT
LIGHT DELAY
KEY BEEP
ENGLISH
ITALIANO
FRANCAIS
DEUTSCH
ESPANOL
SET MEASURE
GYPSY LAP
MAGNETS NUMBER
SENSOR TEST
LCD TEST
SW VERSION
SET DEFAULT
CHECK FLASH
CHECK EEPROM
CAN MESSAGE
LOCKED KEYS
FREE FALL
DATA ITEM SYNTHETIC DESCRIPTION
COUNTER RESET
Reset of the measure of chain lowered.
FUNCTIONS
Automatic down and up alarm setting.
PERSONAL SET
Chain counter personalization: contrast, back-lighting, light delay, key beep, timed locking of the
p and q (UP and DOWN) keys.
LANGUAGE
Language used for system messages
CALIBRATION
Chain counter calibration: setting of the measurement unit, of the number of magnets installed, of the
gypsy lap on the gypsy and management of the windlass with free fall.
AUTO CALIBRATE
Automatic chain counter calibration.
UTILITY
Various chain counter controls.
CAN CONFIG
MASTER/SLAVE setting if more than one chain counter is used.
EXIT
Chain counter set-up menu exit.
