Quick DV5 Dave Series - Technical Data

18
DV5 1700/2000/2300/3000W - IT EN - REV002B
TECHNICAL DATA
EN
a
a b c d a b c d
a a a a a a a
1° EXAMPLE:
DV1712DX
2° EXAMPLE:
DAVE3024Y
DV5 17 12 D DV5 30 24 -
Name of the line:
[ DV5 ] =
base ovale
in acciaio inox AISI 316
Motor output:
[ 17 ]
= 1700 W
[ 20 ] = 2000 W
[ 23 ] = 2300 W
[ 30 ] = 3000 W
Motor supply voltage:
[ 12 ] =
12 V
[ 24 ] = 24 V
[ TR ] = 230 V / 400 V
Drum:
[ D ] =
con campana
[ - ] = senza campana
HOW TO IDENTIFY THE WINDLASS THROUGH THE CODE:
a b c d
(*) The values indicated in the table refer to a rope and chain combination manufactured with the Quick
®
system, do not guarantee the correct functioning with
other types of anchor-rode.
Quick
®
reserves the right to introduce changes to the equipment and the contents of this manual without prior notice.
In case of discordance or errors in translation between the translated version and the original text in the Italian language, reference will be made to the Italian or English text.
F
(1) After an initial period of use.
(2) Measurements taken with a gypsy for a 12/13 mm chain.
(3) Minimum allowable value for a total length L<20m. Determine the cable size according to the length of the wiring.
(4) With circuit breaker designed for direct currents (DC) and delayed-action (thermal-magnetic or hydraulic-magnetic).
(5) On request, shafts and studs can be supplied for greater deck thicknesses.
MODEL DV5 - / D
MOTOR OUTPUT 1700W 2000W 2300W 3000W
Motor supply voltage
12V 24V 24V 24V
Maximum pull 1100 Kg (2425,1 lb) 1200 Kg (2645,5 lb) 1260 Kg (2777,8 lb) 2400 Kg (5291,1 lb) 3100 Kg (6834,3 lb)
Maximum working load 470 Kg (1036,2 lb) 570 Kg (1256,6 lb) 750 Kg (1653,5 lb) 850 kg (1873,9 lb) 1200 kg (2645,5 lb)
Working load 155 Kg (341,7 lb) 190 Kg (418,9 lb) 250 kg (551,1 lb) 285 Kg (628,3 lb) 400 kg (881,8 lb)
Current absorption @ working load
(1)
175 A 100 A 115 A 120 A 145 A
Maximum chain speed
(2)
m/min 36,1 (118,4 ft/min) 38,3 (125,7 ft/min) 41,2 (135,2 ft/min) 41,2 (135,2 ft/min) 39,2 (128,6 ft/min)
Max. chain speed @ working load
(2)
m/min 20,6 (67,6 ft/min) 20,8 (68,2 ft/min) 22,3 (73,2 ft/min) 23,3 (76,4 ft/min) 19,3 (63,3 ft/min)
Sezione minima cavi motore
(3)
50 mm
2
(AWG0) 25 mm
2
(AWG3) 35 mm
2
(AWG2) 35 mm
2
(AWG2) 50 mm
2
(AWG0)
Interruttore di protezione
(4)
100 A 60 A 80 A 80 A 100 A
Deck thickness
(3)
40 ÷ 80 mm (1” 9/16” ÷ 3” 5/32)
Weight - model without drum 33,6 kg (74,1 lb) 39,3 kg (86,6 lb) 51,0 kg (112,4 lb) 61,3 kg (135,1 lb)
Weight - model with drum 37,0 kg (81,6 lb) 42,7 Kg (94,1 lb) 54,4 Kg (119,9 lb) 64,7 Kg (142,6 lb)
Chain pipe:
[ X ] =
right chain pipe
[ Y ] = left chain pipe
e
MODEL DV5 - / D
MOTOR OUTPUT 3000W TR
Motor supply voltage
230/400 V
Maximum pull 2800 Kg 6172,9 lb
Maximum working load 930 Kg 2050,3 lb
Maximum chain speed
(2)
15,4 m/nm 50,5 ft/min
X
e
a
Y
e
a
Models’ dimensions on page 32/33
GYPSIES 10 mm - 3/8” 12/13 mm 14 mm
Chain size
10 mm 10 mm 3/8” 3/8” 13 mm 12 mm 7/16” 14 mm 14 mm 1/2”
DIN 766 ISO G4 BBB DIN 766 ISO G4 DIN 766 ISO G4
Rope size (*) 3/4” (19 mm) 3/4” (19 mm) 3/4” (19 mm)
