6
IT
HECTOR 700/1000/1500W - REV008A
SISTEMA BASE
PULSANTIERA
MULTIUSO
MOD. HRC 1002
SALPA ANCORA
BATTERIA
INTERRUTTORE
MAGNETO IDRAULICO
(VEDI TABELLA PAG, 4)
PULSANTI A PIEDE MOD. 900U E 900D
BLU
MARRONE
NERO
NERO
BLU
FUSIBILE
4A (12V)
2A (24V)
L = L1 + L2 + L3
NERO
MARRONE
BLU
BIANCO
VERDE
CAVI SENSORE
CONTACATENA
ROSSO
NERO
L1
L2 L3
SCHEMA DI COLLEGAMENTO
CONTACATENA
DA PANNELLO
COMANDO
DA PLANCIA
PULSANTIERA
CONTACATENA
TASCABILE - PULSANTIERA
RICEVITORE
ACCESSORI QUICK
®
PER L'AZIONAMENTO
DEL SALPA ANCORA
TRASMETTITORI
RADIOCOMANDI
