TECHNICAL DATA
EN
RG5 1700/2000/2300/3000W IT EN - REV006A
Quick
®
reserves the right to introduce changes to the equipment and the contents of this manual without prior notice.
In case of discordance or errors in translation between the translated version and the original text in the Italian language, reference will be made to the Italian or English text.
F
aa bb cc dd ee
a
a
a
a
a
a
a
a
a
a
1°
EXAMPLE
:
RG51712DX
2° EXAMPLE:
RG530TRDY
RG5RG5 3017 TR12 DD YX
Name of the line
:
[ RG5 ] =
base in
stainless steel
with chain pipe
Motor output:
[ 17 ]
= 1700 W
[ 20 ]
= 2000 W
[ 23 ]
=
2300 W
[ 30 ]
=
3000 W
Motor supply voltage
:
[ 12 ]
=
12 V
[ 24 ]
=
24 V
[ TR ]
=
230 V / 400 V
Drum
:
[ D ] =
with drum
[ - ]
= without drum
Chain pipe:
[ X ] =
right chain pipe
[ Y ]
= left chain pipe
a b c d d
HOW TO IDENTIFY THE WINDLASS THROUGH THE CODE:
Models’ dimensions on page 32/33
(*) ISO EN 818-3.
(1) After an initial period of use.
(2) Measurements taken with a gypsy for a 12/13 mm chain.
(3) Minimum allowable value for a total length L= < 20m. Determine the cable size according to the length of the wiring.
(4) On request, shafts and studs can be supplied for greater deck thicknesses.
MODEL RG5 X/Y - / D
MOTOR OUTPUT 1700W 1700W 2000W 2300W 3000W
Motor supply voltage 12V 24V 24V 24V
Maximum pull 1100 Kg (2425,1 lb) 1200 Kg (2645.5 lb) 1260 Kg (2777.8 lb) 2400 Kg (5291.1 lb) 3100 Kg (6834.3 lb)
Maximum working load 470 Kg (1036,2 lb) 570 Kg (1256.6 lb) 750 Kg (1653.5 lb) 850 kg (1873.9 lb) 1200 kg (2645.5 lb)
Working load 155 Kg (341,7 lb) 190 Kg (418.9 lb) 250 kg (551.1 lb) 285 Kg (628.3 lb) 400 kg (881.8 lb)
Current absorption @ working
load
(1)
175 A 100 A 115 A 120 A 145 A
Maximum chain speed
(2)
36,1 m/mm
(118,4 ft/min)
38,3 m/min
(125.6 ft/min)
41,2 m/min
(135.2 ft/min)
41,2 m/min
(135.2 ft/min)
39,2 m/min
(128.6 ft/min)
Maximum chain speed @ working
load
(2)
20,6 m/mm
(67,6 ft/min)
20,8 m/min
(68.2 ft/min)
22,3 m/min
(73.2 ft/min)
23,3 m/min
(76.4 ft/min)
19,3 m/min
(63.3 ft/min)
Motor cable size
(3)
50 mm
2
(AWG 0) 25 mm
2
(AWG 3) 35 mm
2
(AWG 2) 35 mm
2
(AWG 2) 50 mm
2
(AWG 0)
Deck thickness
(3)
40 ÷ 80 mm (1” 9/16” ÷ 3” 5/32)
Weight without drum 34,6 kg (76.3 lb) 34,6 kg (76.3 lb) 39,5 kg (87.1 lb) 48,7 kg (107.4 lb) 59,4 kg (131.0 lb)
Weight with drum 39,0 kg (86.0 lb) 39,0 kg (86.0 lb) 43,9 Kg (96.8 lb) 53,1 Kg (117.1 lb) 63,8 Kg (140.7 lb)
GYPSY 10 mm - 3/8” 12/13 mm 14 mm
Chain size
10 mm 10 mm 3/8” 3/8” 13 mm 12 mm 7/16” 14 mm 14 mm 1/2”
DIN 766 ISO (*) G4 BBB DIN 766 ISO (*) G4 DIN 766 ISO (*) G4
MODEL RG5 X/Y - / D
MOTOR OUTPUT 3000W TR
Motor supply voltage
230/400 V
Maximum pull 2800 Kg (6172.9 lb)
Maximum working load 930 Kg (2050.3 lb)
Maximum chain speed
(2)
15,4 m/min (50.5 ft/min)
Weight without drum 64,0 kg (141.1 lb)
Weight with drum 66,2 Kg (145.9 lb)
