HYDRAULIC MOTOR
POS. DESCRIPTION
50 GEARBOX - 2000W - QUICK SERIES
51 SCREW
52 GROWER
53 O-RING
77 FLANGE
78 ADAPTER TG70
79 KEY
80 BIDIRECTIONAL GEAR-TYPE MOTOR
17,9CC
81 FLANGE 90° G3/4 FEMALE
82 SCREW
HYDRAULIC WINDLASS
BASIC SYSTEM HYDRAULIC RG5
CONNECTION DIAGRAM
PRESSURE
INPUT
TANK
SELECTOR
VALVE
WATERTIGHT PANEL
CHAIN COUNTER CHC 1202 M
WINDLASSES
CONTROL
BOARD
MOD.800
WATERTIGHT
HAND HELD
CHAIN COUNTER
MOD. CHC 1002 M
HANDHELD
MOD. H02
RECEIVER
MOD. R02
QUICK
®
ACCESSORIES
FOR HYDRAULIC WINDLASS OPERATION
TRANSMITTERS
RRC REMOTE RADIO CONTROLS
RADIO POCKET
MOD. P02
MULTI-PURPOSE
WATERTIGH
HAND HELD
REMOTE CONTROL
MOD. HRC 1002
FOOT SWITCH
MOD. 900U AND 900D
