27
ENGLISH
Nitrum / Nitrum Hybrid Rev.C
Total width:
With 25" standard wheels, incl. handrims with 6° camber: SW + 300 mm
Overall length: 930 mm with SD 500
Total height: 950 mm with BH 450
Weight in kg: from 6.5 kg
Maximum load:
Nitrum 125 kg (140kg with optional Hybrid frame).
Seat heights:
The choice of frames, forks and castors, as well as the rear wheel size (24”, 25”) determines the seat heights which can be achieved.
Norm Min. Max. Norm Min. Max.
Overall length with
footrest
770 mm 930 mm Seat surface angle 0° 16°
Overall Width 490 mm 860 mm Effective seat depth 340 mm 500 mm
Folded length N/A N/A Effective seat width 320 mm 500 mm
Folded width N/A N/A Seat surface height at
front edge
430 mm 570 mm
Folded Height N/A N/A Backrest angle 59° 105°
Total Mass 6.5 kg 13.0 kg Backrest height 250 mm 450 mm
Slope for the use of
the wheel locks
0° 7° Turning radius 700 mm
Mass of the heaviest
part
- 2.1 kg with
24" rear wheel
*
Distance from the
footrest to the seat
220 mm 520 mm
Static stability
downhill
10° 10° Angle from leg to seat 88° 100°
Static stability uphill
with anti-tip tubes
10° 10° Distance from the
armrest to the seat
N/A N/A
Static stability
sideways
10° 10° Front location of
armrest structure
N/A N/A
Dynamic stability -
uphill power
consumption
N/A N/A Handrim diameter 540 mm 567 mm
Overcoming
obstacles
N/A N/A Horizontal location
of axle
+ 104 mm + 20 mm
12.0 Technical Data
*Standard wheel with stainless steel handrim
The wheelchair conforms to the following standards:
a) Requirements and tests for static strength, impact resistance and fatigue strength (ISO 7176-8) Yes.
b) Drive and control systems for power wheelchairs, requirements and test (ISO 7176-14) n.a.
c) Environmental test in accordance with ISO 7176-9 n.a.
d) Flammability resistance of upholstered parts in accordance with ISO 7176-16 (EN 1021-1/2) Yes.
