Quickie Nitrum User Manual

30
ENGLISH
Nitrum / Nitrum Hybrid Rev.C
13.0 Torque
Torque.
NOTE: Wherever torque settings are specified, it is strongly recommended that a torque meter (not included), is used to verify correct
torque specification is achieved.
If no other information is given, the generic torque for M6 screws is 7 Nm.
CAUTION: Some of the screws that are used during manufacture are fitted with threadlock, (blue dot on the thread) and can be undone
and re-tightened up to three times before they must be replaced with new screws and threadlock. Alternatively, you can put Loctite™
243 threadlock on the screws and re-fit them.
20 Nm
20 Nm
7Nm
7Nm
10Nm

Quickie Nitrum Specifications

General

Frame Type	Rigid
Foldable	No
Armrests	Optional
Seat Width	20 inches
Seat Depth	20"
Backrest Height	8.5"
Front Frame Angle	75°, 85°
Wheel Size	24, 25, 26 inches
Front Casters	3", 4", 5", 6"
