39 Revolution
Issue 5
Overall length with legrest 813mm min. 892mm max.
Overall width 677mm
Folded length 690mm
Folded width 558mm
Folded height 285mm
Total mass 12.5kg
Mass of heaviest part 9.5kg
Static stability downhill Less than 1°
Static stability uphill Less than 1°
Static stability sideways Less than 1°
Seat plane angle 16.5°
Effective seat depth 480mm
Effective seat width 416mm
Seat surface height at front edge 443mm
Backrest angle 16.5°
min. 25.5°
max.
Backrest height 350mm min. 425mm max.
Footrest to seat distance 370mm min. 460mm max.
Leg to seat surface angle 90°
Armrest to seat distance Not applicable
Front location of armrest structure Not applicable
Handrim diameter 532mm
Horizontal location of axle 50mm min. 120mm max.
Minimum turning radius 580mm
Technical data
Revolution
