7.0 Control System
7.0 R-net control system information
An alternative control system called R-net is available as
an option for the wheelchair.
The R-net system has extended options and is suitable
for individuals with complex needs or when there
is a preference for screen based menu options and
information displays.
The R-net control system offers simple, effective
solutions to many situations, thereby enhancing the
lifestyle and independence of the user.
The operation of the R-net wheelchair control system is
simple and easy to understand. Both the R-net and VR2
control systems incorporates state-of-the-art electronics,
the result of many years of research, to provide you with
ease of use and a very high level of safety.
Because of the comprehensive nature of the R-net
control system, a separate R-net Owner’s Manual is
supplied whenever this system is fitted.
Please refer to the R-net Owner’s Manual for
details of R-net hand control functions.
Fig. 6.33
6.18.4 Quickie Direct Actuator Control Box (Fig.6.33)
To operate the backrest, seat lift, seat tilt:
• Push the relevant toggle switch into the forward
position.
• Release the toggle switch when the desired backrest
angle, seat lift height or seat tilt angle is reached.
CAUTION!
Once the back is fully reclined/forward, or the lift is fully
raised/lowered, or the seat is fully tilted backwards/
forwards, do not continue to hold the switch in its operating
position as this could damage the actuator.
7.1 VR2 control system information
On/off button:
The on/off button applies power to the control system
electronics, which in turn supply power to the wheelchairs
motors.
CAUTION!
Do not use the on/off button to stop the wheelchair unless
there is an emergency. (If you do you may shorten the life
of the wheelchair drive components)
