SAMBA
This section is designed to assist you in keeping a record of any
service and repairs to your wheelchair. The service Agent will
complete this section and return the manual to you.
Service History Specification
Min. Max.
Effective seat width 350 mm 500 mm
Effective seat depth 380 mm 480 mm
Backrest height 380 mm 480 mm
Overall length (w/legrest) 1040 mm
Overall width 610 mm 635 mm
Climbing ability upwards 10° (18%)
Seat surface height at front edge 450 mm 510 mm
Ground Clearance 80 mm
Footrest to seat distance 350 mm 490 mm
Armrest to seat distance 180 mm 300 mm
Folded length N/a
Folded width N/a
Folded height N/a
Samba2 Total mass (with batteries) 98 kg 110 kg*
Samba2 lite Total mass (with batteries) 98 kg 120 kg*
Seat plane angle -5º 20°
Backrest angle -10º 40°
Leg to seat surface angle 70º 90°
Max. Speed forward 6 km/h.
Obstacle climbing (w/kerb climb.) 50 mm (100 mm)
Max. safe slope 10°
Min. Turning radius 900 mm
Max. User weight 120 kg
Max. Range (ISO 7176; Part 4) 25 km 32 km
Mass of the heaviest part 31 kg
(drive units without batteries)
*In its heaviest configuration
Replacement units are available on request by the dealer for
repairing or changing. Please refer to the SAMBA parts manual
available.
Note: Only use Sunrise Medical parts for service and repairs
Model
Serial No.
Year 1234
Service dates
Controller
On/Off switch
Output plug
Operation
Dynamic braking
Programmable configuration
Batteries
Levels
Connections
Discharge tests
Wheels/Tyres
Wear
Pressure
Bearings
Wheel nuts
Motors
Wiring
Noises
Connections
Brake
Brushes
Free wheel mechanism
Chassis
Condition
Steering
Fasteners
Upholstery
Seat
Back
Armrests
Electric's
Condition of loom
Connections
Test run
Forward
Reverse
Emergency stop
Left run
Right run
Up/down slope
Over obstacle
Parking brake
