Quickie Tango 17
Ensure that there is no excess belt material looping out of
the male buckle, (Fig.4.16)
When fastened check space between the lap belt and
the user, when correctly adjusted it should be possible to
insert the flat of the hand between the lap belt and the
user, (Fig.4.17).
Generally the Lap Belt should be fixed so that the straps
sit at an angle of approximately 45°, and when correctly
adjusted should not allow user to slip down in the seat,
(Fig.4.18).
To fasten buckle:
Firmly push the male buckle into female buckle,
(Fig.4.19).
To release belt:
Press the exposed sides of the male buckle and push
towards the centre whilst gently pulling apart, (Fig.4.20).
WARNING!
Do not rely on the lap belt only when the wheelchair and
occupant are transported in a vehicle, use the separate
occupant lap and diagonal restraints provided in the
vehicle, (Fig 4.7).
Fig.4.19
Fig.416
Fig.4.17
Fig. 4.18
Fig.4.20
