Quickie Xplore User Manual

N. CG TILT POWER ACCESSORY
WARNING
The powered CG Tilt accessory for this chair has a
maximum user weight capacity of up to 400 lbs. Never exceed
this capacity while operating the powered actuator.
O. LIFT POWER ACCESSORY
WARNING
The powered lift modular accessory for this chair has a
maximum user weight capacity of up to 300 lbs. Never
exceed this capacity while operating the powered actuator.
P. POWER RECLINE
WARNING
Pinch Point
Avoid putting hands or fingers near the power recline mechanism
while in operation.
Weight Capacity
The maximum user weight capacity for the power recline is up to
400 lbs. Exceeding this weight capacity could lead to injury and/or
permanent damage to the equipment.
Q. POWER LEGREST ACCESSORY
The power legrest accessory for the Xplore has a maximum user
weight capacity of up to 300 lbs or 400 lbs depending on your chair
configuration. Never exceed this capacity while operating the
powered actuator.
R. TRANSIT USE
The chair has been manufactured with built-in Transport Brackets
on.
WARNING
These transport brackets have not been crash-tested in accor-
dance with AINSI-RESNA WC-19. Use these transport brackets
only to secure an unoccupied wheelchair during transport
1. NEVER let anyone sit in this chair while in a
moving vehicle.
2. NEVER transport this chair in the front seat
of a vehicle. It may shift and interfere with the
driver
3. ALWAYS secure this chair so that it cannot roll
or shift.
4. Do not use any chair that has been involved in
a motor vehicle accident.
VIII. SET UP, ADJUSTMENT AND USE
NOTES
1.Work Surface For Set-Up:
Use a flat surface, such as a table, to assemble, adjust and check your
chair. This makes the steps easier and helps ensure a correct set-up.
2. Fasteners:
• Many of the screws and bolts on this chair are special high-
strength fasteners and may have special coatings.
• Many nuts are of the Nylock type. They have a plastic insert
to help prevent loosening.
• Only use screws, bolts and nuts provided by Sunrise.
WARNING
1. Use of improper fasteners may cause the chair to fail.
2. Over- or under-tightened fasteners may fail or cause
damage to chair parts.
3. If bolts or screws become loose, tighten them as soon
as you can. Loose bolts or screws can cause damage to
other chair parts causing them to fail.
3. Washers & Spacers:
• Note the position of washers and spacers before disassembly.
• To avoid damage to the frame, replace all washers and spac ers
when you reassemble parts.
TOOLS YOU WILL NEED
1. Basic Tool Kit:
To set-up, adjust and maintain your chair you may
need the
following tools:
• Combined Phillips and flat screw driver
• Standard metric wrenches from 10mm
• Metric Allen wrenches from 5mm
• Imperial wrenches from 1/4" to 9/16"
• Imperial Allen wrenches from 5/64" to 1/4"
You can obtain a multi-purpose tool kit from Sunrise, or
buy the tools you need from a hardware store.
2. Torque Wrench:
If you plan to adjust and maintain this chair yourself,
Quickie
recommends that you use a torque wrench.
Q-NOTE- The wrench must measure inch-pounds (N.m). You can
buy
a torque wrench and proper sockets from a hardware store.
Quickie Xplore Owner’s Manual Rev. B 13.
