Assemble the Attaching tubes CROSSBAR , MF8-1 to MF-1,MF-2 & MF-5 connectors.
CROSSBAR
STEP C
MF-5
MF-5
MF-5
MF-2
MF-5
MF-2
DETAIL VIEW
DETAIL VIEW
MF8-1
MF-2
