STEP G
Attach the CROSSBAR & POSTS to the BASE FRAME using the connectors.MF-2
CROSSBAR TO BASE FRAME
MF8-3
MF8-1
MF-2
MF8-3
MF-2
MF8-1
DETAIL VIEW
MF-2
MF8-3
MF8-1
