Quicksilver 455CAB — Electrical Systems
25
5. Fuses and Breakers
Your boat will either have fuses or breakers protecng the DC electrical system. If you have to replace
a fuse or electrical breaker, replace only with a fuse or breaker of the same rang. The amperage will
be marked on the fuse or breaker, and it is recommended that you carry spare fuses or breakers.
Use only fuses and breakers having the same amperage
rang as the original or as specied. Use of higher
amperage fuses or breakers is a re hazard.
Located next to the baery switch in the center cockpit oor hatch, there are 2 fuse holders. The
upper fuse holder houses a 20A main fuse for the boat. The lower fuse holder is a 3A fuse for the bilge
pump.
Fuses and Breakers
ATO/ATC fuse Thermal breaker ANL fuse Magnec breaker
If a fuse or breaker is replaced with one that has a lower amperage, it may not be sucient to carry
the electrical load of the equipment it is connected to and will cause nuisance failures. If a fuse or
breaker is replaced with one that has a higher amperage, it will not provide protecon against an
electrical malfuncon and could create a possible re hazard.
Main Fuses
Main fuse — 20 Amp
Auto bilge pump fuse — 3 Amp
At the helm, there is an addional fuse panel accessible from the interior of the cabin. To access,
simply remove the vinyl fabric panel covering the dash components.
