5. Fuses and Breakers
Your boat will either have fuses or breakers protecng the DC electrical system. If you have to replace
a fuse or electrical breaker, replace only with a fuse or breaker of the same rang. The amperage will
be marked on the fuse or breaker, and it is recommended that you carry spare fuses or breakers.
Use only fuses and breakers having the same amperage
rang as the original or as specied. Use of higher
amperage fuses or breakers is a re hazard.
Located on the baery switch panel, there are two thermal breakers, while at the helm, there is a
breaker panel located below the steering wheel.
Fuses and breakers
ATO/ATC fuse Thermal breaker ANL fuse Magnec breaker
If a fuse or breaker is replaced with one that has a lower amperage, it may not be sucient to carry
the electrical load of the equipment it is connected to and will cause nuisance failures. If a fuse or
breaker is replaced with one that has a higher amperage, it will not provide protecon against an
electrical malfuncon and could create a possible re hazard.
Main Fuses
Baery switch panel
Main fuse — 20 Amp
Auto bilge pump fuse — 3 Amp
