Quietside QVM 9-090W1-NG User Manual

41 QVM 9 Series
 Models : QVM9-090/125/150W1-NG
(UNIT : mm)
No Part Code Part Name Q’ty Material Remarks
37 C21019041B BH1407023A Air Pressure Switch 1 QVM9-090/125W1, ON:30~OFF34 mmH
2
O
C21019042B BH1407024A 〃 1 QVM9-150W1, ON:41~OFF45 mmH
2
O
38 C21007017A BH1403003A Heating Temperature Sensor 1 All QVM9, PB-3M-K42D-MD1
39 C21610014A BH2507030A Heating Temperature Sensor O-Ring 1 EPDM All QVM9, P3
40 C21707133A PH1603008A Electrode and Flame Detection 1 All QVM9
41 C21703105B PAC160KC_032 Heat Exchanger(Sensible Heat) 1 Cu QVM9-090W1
C21703107B PAC250KC_033 〃 1 Cu QVM9-125W1
C21703132A PAC301KC_034 〃 1 Cu QVM9-150W1
42 C21703106B BH2501231A Heat Exchanger(Latent Heat) 1 STS304 QVM9-090W1
C21703108B BH2501232A 〃 1 STS304 QVM9-125W1
C21703133B BH2501233A 〃 1 STS304 QVM9-150W1
43 C21606015A BH2406006A Duct Packing 1 SILICON QVM9-090W1
C21606017A BH2406007A 〃 1 SILICON QVM9-125W1
C21606030A BH2406008A 〃 1 SILICON QVM9-150W1
44 C21705049B BH2501075A Exhaust Duct 1 ALDC QVM9-090/125W1
C21705057B BH2501076A 〃 1 ALDC QVN9-150W1
45 C21709041A BH2501211A Duct Flow Guide 1 AL. STAR QVM9-090W1
C21709042A BH2501212A 〃 1 AL. STAR QVM9-125W1
C21709092A BH2501213A 〃 1 AL. STAR QVM9-150W1
46 C21705050B BH2501072A Duct 1 ALDC QVM9-090W1
C21705051B BH2501073A 〃 1 ALDC QVM9-125W1
C21705058A BH2501074A 〃 1 ALDC QVM9-150W1
47 C21708380A BH2507039A Gas Inlet Pipe 1 STS304 QVM9-090W1
C21708381A BH2507040A 〃 1 STS304 QVM9-125W1
C21708382A BH2507041A 〃 1 STS304 QVM9-150W1
48 C21708252A BH2507057A Gas Control Valve Outlet Connection 1 ALDC All QVM9
49 C21708269B BH2507164A Heat Exchanger Outlet Pipe 1 C1220T QVM9-090W1, φ14X0.7T
C21708272A BH2507165A 〃 1 C1220T QVM9-125W1, φ14X0.7T
C21708310A BH2507166A 〃 1 C1220T QVM9-150W1, φ14X0.7T
50 C30109013A BH0901012A Modulating Gas Control Valve 1 All QVM9, SIT-822 NOVAMIX
51 C21708251A BH2507055A Gas Inlet Connection 1 C3712BD All QVM9, PT 3/4˝
52 C21703109A BH2501228A Domestic Water Heat Exchanger 1 QVM9-090W1, 16 pieces
C21703110A BH2507033A 〃 1 QVM9-125W1, 18 pieces
C21703134A BH2501229A 〃 1 QVM9-150W1, 20 pieces
53 C21708265A BH2507060A Domestic Hot Water Inlet Pipe 1 C1220T All QVM9
54 C21708266A BH2507065A Domestic Hot Water Outlet Pipe 1 C1220T All QVM9
55 C21708257A BH2507178A Domestic Hot Water Connection 1 C3712 All QVM9
56 C21213012B BH1408007A Domestic Hot Water Flow Switch 1 NYLON 66 All QVM9
57 C21708256A BH2507176A Tap Water Inlet Connection 1 C3712 All QVM9
58 C20315002C BH0906001B Automatic Water Supply Valve 1 All QVM9
59 C20701081A BH1202007A Main Power Transformer 1 All QVM9, PT-6645K
60 C20405004B BH1001001A Heating Pressure Gauge 1 All QVM9
61 C21750165A BH2501217A Heating Pressure Gauge Bracket 1 SBHG1 All QVM9
62 C20301005B BH2507005A Manual Air Vent 1 All QVM9, 0 ~ 4 kPa
63 C20701082A BH1204002A Boost Transformer for Gas Valve 1 All QVM9, PT-4117L
64 C21005095E NARC1GSFR503 Room Thermostat 1 All QVM9, FR-5
65 C21405160A BH2101056A Harness(Wires) Assembly 1 All QVM9
66 C21405164A BH2103002A Power Code Wire 1 All QVM9
Parts List
