Quooker COMBI - Overview of Fusion Tap Installation; B2. Fitting Fusion tap

Overview of Fusion tap installation
It is recommended that you install the Quooker system in the following order:
A. Drilling hole
B2. Fitting Fusion tap
C. Connecting water
D. Connecting tank
Note: Bear in mind that the tank, mixing valve and socket must remain accessible for servicing.
For an overview of the Flex tap installation, please refer to the next page.
Cold
A B
2
C
D
