Quooker Scale Control Plus - Installing the Scale Control R Meter; Connecting the Tap; Connecting the Scale Control Plus Meter

1
3
2
4
D
1. Connecting the tap
Detach the tap's jack plug from the tank
and insert it into the jack plug socket of
the Scale Control Plus Meter.
2. Connecting the Scale Control
Plus Meter
Insert the jack plug of the Meter into the
inside port, closest to the centre of the
Quooker tank.
3. Mounting the metal washer
Screw the washer provided into the
kitchen cabinet using the screw provided.
4. Securing the Scale Control Plus
Meter
Mount the Meter onto the metal washer
using the magnet on the back of the
Meter. Ax the sticker provided next to
the Meter on the inside of the cabinet.
Installing the Scale Control R Meter (for systems installed after October 2017)
