R volution PlayerOne - Front View Description; Front Panel Components Layout; Rear View Description; Rear Panel Connectivity Ports

1043
2
5 6
7
8 9 11 12
13
1
1415 17
1
16
6
1. Wi-Fi Antenna
2. Analog Audio Output Right / Left
3. Analog Video Output CVBS
1. LCD Screen
2.
POWER ON/Sleep
3. USB 2.0 Host
4. Door of the HDD Rack Enclosure
4. Coaxial Digital Audio Output
5. Optical Digital Audio Output
6. Audio HDMI Output (Audio only)
9. HDMI Input 18. Power Input
10. IR IN (IR extenter included)
11. LAN 10/100/1000
12. USB 2.0 Host
13. USB TYPE-C
14. USB 3.1 Host
15. Ground
16. RF Antenna
17. Power ON/OFF
7. Main HDMI Output (Video + Audio)
8. Restore
Rear View
Front View
1
2
3
Quick Start Guide
18
4
