RaceChip XLR - Cable Management

8
2 Installation
A. On the left of the footwell next
to the footrest
B. Under the trim on the centre tunnel
• Use the cable clips and/or cable ties to secure the cable between the Brainbox and the
gaspedal, ensuring that nothing interferes with the pedals.
2x cable clips 4x cable ties
cable clips
A2
cable clips
B2
