© 2011 Racktivity Inc. 14/25
2100 Seaport Blvd., Suite 400, Redwood City 94063, USA – www.racktivity.com v 2013.11.18
The following settings are only available when the DHCP checkbox is unchecked:
Ethernet (Warning: when changing these values connection to the Web Portal might be lost)
• IP-Address: The IP-address used for TCP/IP configuration
• Subnetmask: The subnet mask used for TCP/IP configuration
• Std Gateway: The standard gateway used for TCP/IP configuration
• DNS-server: The DNS-server used for TCP/IP configuration
• DHCP: When checked the PDU will automatically be assigned an IP-address (if a DHCP
server is present on the network)
SNMP
• Community read: Sets the community read string, default: "public". When using SNMP
software on a pc to collect SNMP data (GET command) this string is used as verification
• Community write: Sets the community write string, default: "private". When using SNMP
software on a pc to change SNMP data (SET command) this string is used as verification
• Write protection: When checked this setting will prevent changes being made through
SNMP (SET command), even when using the correct Community write string. It can be
used as an additional protection
• Trap receiver port: Sets the port for the SNMP Trap function, default: "162"
• Trap receiver IP: Sets the IP address where the SNMP Trap is sent, this is normally the IP
of a monitoring computer on the same network
OLED
• Min. before Off: Sets the OLED standby delay when no buttons are pressed (in minutes)
• Brightness [2-10]: Sets the OLED's brightness
• Login: Sets a new login and password. The default values are:
Login: admin
Password: 1234
Logging
• Sets the logging values for the Logging tab
o Short term: From 1 - 255 seconds
o Medium term: From 1 - 255 minutes
o Long term: From 2 - 255 medium term intervals (specified in the above setting)
After editing the settings on the Settings tab, press the Save Data button. A pop-up will appear
after the changes have been successfully saved.
Time Settings (UTC)
The following settings are only available when NTP is unchecked
• Time (HM): Sets the time (in hours:minutes)
• Date (DMY): Sets the date (in days/months/years)
• Local NTP-server: NTP server IP when Use Default NTP Server is not checked
• Use Default NTP server: When checked the PDU will connect to pool.ntp.org for the time
settings
• NTP: When checked the PDU will try to get time settings from an NTP server
