4.1 Operating Buttons and Indicator Light
Pos. Symbol Description
1)
2)
+
Up/Stop button + Down/Stop button
The roller shutters travel up / down or stop
3) Indicator Light - Status Display
green ashes
briey
continuous
light
◆ Connection is active
◆ When conguring the sunshine position
◆ 5 sec = connection / disconnection was successful
◆ 5 sec = clearing was successful
red ashes
briey
ashes
briey
continuous
light
◆ Return signal when pressing the setting buttons
◆ Disconnect or clearing is active
◆ When conguring the end points
◆ Resetting is carried out
◆ The running time limit is triggered
◆ 5 sec = connection / disconnection failed
◆ 10 sec = automatic functions = ON
4)
Set button
Setting both end points
5)
AUTO
AUTO button
Switching the automatic functions on/o
6)
DuoFern button (connect / disconnect)
Logging on/o in the DuoFern radio network
1)
2)
3)
4)
5)
6)
