Additional information about conguring the end
points
The end points must be congured for the roller shutters
to stop at the desired upper and lower positions.
It is imperative that both end points are congured,
otherwise malfunctions may occur.
13. End point adjustment
Set the upper end point
1. +
Simultaneously press and hold the
buttons.
(red) The roller shutter travels upwards and
the indicator light ashes red.
1.1 Tighten the belt slightly, until it is tensioned by the
weight of the roller shutters.
2. +
Release the buttons, as soon as the roller
shutter reaches the desired position for
the upper end point.
The roller shutters stop and the upper
end point is stored.
ATTENTION!
Setting the wrong upper end point may lead to
overload or damage the RolloTron Swivel Winder
Standard DuoFern or the drive.
◆ Do not set the upper end point right up to the limit
stop.
◆ Release the button promptly and never allow it to
extend beyond the respective end point.
i
If the RolloTron Swivel Winder Standard
DuoFern is operated without an end point
setting, the drive will continue to run as long
as one of the two control buttons is actuated.
The automatic functions remain blocked
until the end point setting is congured.
