RADEMACHER DuoFern 2510 User Manual

63
EN
6.2 Permissible roller shutter belts
i
ATTENTION!
The RolloTron Swivel Winder Standard DuoFern may
be damaged if excessively long belts are used.
Only use belts of the permissible lengths.
Table 1: Permissible roller shutter belts
RolloTron swivel winder:
Item no.:
Standard DuoFern (Mini-belt)
1415 30 11
Standard DuoFern
1423 30 11
Belt width:
Belt thick-
ness:
Maximum belt length
15 mm (Mini-belt) 1.0 mm 5 m
23 mm (Standard belt)
1.0 mm 5 m
1.3 mm 4 m
1.5 mm 3.4 m
Table 2: Permissible shutter surface area (m
2
)
Roller shutter type: Weight/m
2
Permissible shutter surface area (m
2
)
Plastic roller shutters (4.5 kg/m
2
) Approx. 5 m
2
Approx. 5 m
2
Aluminium and wooden roller
shutters
(10.0 kg/m
2
) Approx. 2.5 m
2
Approx. 2.5 m
2
i
The specications are intended for guidance
only and apply to an ideal installation situation.
The actual values may vary due to local
conditions.

RADEMACHER DuoFern 2510 Specifications

General

Communication Protocol	DuoFern
Protection Class	IP20
Compatibility	DuoFern
Maximum Load	1000 W
Operating Temperature	0°C up to +40°C
