10.0 RD-30 Status Indicator LED
The RD-30 has the ability to run diagnostics on itself. On the front panel an LED is used as a
status indicator. The following table will help dene the status of the RD-30 when the unit is
powered up.
Solid Yellow RD-30 in full Auto-Calibration mode.
Solid Green All Systems Operational.
Flashing Yellow Boot Loader Mode, used for hardware upgrades.
Solid Red Hardware Failure
Flashing Red Memory Error/Auto-Calibration Error.
Upon power up the RD-30 is design to run a full Auto-Calibration. Once calibration is complete
the LED will change to solid green. If the LED ashes Red after the Auto-Calibration then it
failed to calibrate correctly.
