RD-30 Operations Manual
Step2
Initiate power on the potential and current sources. Apply power to the RD-30. Upon successful
power up, the RD-30’s LED will be green and RR-MobileSuite will have launched (see Section
8.1).
Step3
Using the stylus, single tap on the Run Meter Test icon. The meter test screen will now appear
(see Section 8.8).
Step4
Use the onscreen keyboard (see Section 8.10) to enter the DUT serial number
Step5
Use the onscreen keyboard to enter DUT Kh value.
Step6
Use the stylus and the arrow keys on the Meter Test screen to enter/select the Pulses per Kh, #
Seconds or Pulses, DUT Elements, Test Type, Standard Elements, Phase and State. Be sure to
deselect Sensor for this manual test. Repeat Step 6 for all applicable DUT(s).
Step7
Use the stylus and the arrow keys on the Meter Test screen to enter/select the number of repeats to
perform.
Step8
Use the stylus and navigate to the Run Tab. The test routine is now awaiting an input from the
RM-1S. When the ag on the meter disk appears, depress the RM-1S switch to begin the test.
This will be the start of the rst disk revolution of the test. Depress the RM-1S each time the ag
appears until the number of pulses has been achieved.
Step9
Once complete, the Percent Registration, Percent Error, Test Status, Metric Value, Function Tested,
Minimum Percent Registration, Minimum Percent Error, Minimum Percent Pulses, Minimum
Percent Metric, Standard Deviation of Percent Registration, Standard Deviation of Percent Error,
Standard Deviation of Number Pulses and Standard Deviation of the Metrics being tested are
reported.
