Radian RD-30 - RM-OA Optical Adapter

RD-30 Operations Manual
RM-OAOpticalAdapter
The RM-OA Optical Adapter is used with solid-state meters whose infrared calibration pulse is emit-
ted from the optical communications port. The RM-OA magnetically couples to the communication
port of solid-state meters. The suction cup of the RD-1H is attached to the clear polycarbonate cover
of the RM-OA. The RM-OA incorporates a rare earth permanent magnet for exceptional holding
power over the life of the product.
RR-KYZPulseInputAdapter
The RR-KYZ Pulse Input Adapter is used to sense the KYZ output pulses of induction or solid-state
meters. The Pulses received from the meter’s KYZ output are conditioned and fed into the PICKUP
port on the RD-30. The testing of KYZ equipped meters is done automatically with the Built-in
Computer option of the RD-30.
Test Accessories
64
