Installation and Owner’s Manual – Radiant
®
Heat Pump
9
H4121 025960 Rev. B
• A properly authorised electrical
contractor must connect the unit.
• The unit is rated at 10 amps (2
core and earth) so the power mains
supplying the unit must have a 10
amp minimum double pole circuit
breaker tted.
• The electrical connection must
comply with local supply authority
regulations and AS3000.
• The unit
must be connected to:
- CONTINUOUS TARIFF, single
phase 240 volt AC supply.
- Tariff 33 (QLD only), single phase
240 volt AC supply.
• The mains AC supply connection is
located under a plate located on the
side of the tank.
• A qualied electrician may remove
the access cover by undoing the two
screws on the cover and sliding the
cover downward to disengage it.
Caution: The water heater
must be lled with water
before turning on the
electricity supply.
Installation Instructions
Access
Cover
